Feeder Calibration Jig

We have two kinds of Feeder Calibration Jigs, one kind is with X,Y,Z three axises, we say traditional one, in the past days, most people use this one, as the left one, another kind is without X,Y,Z three axises,you can press buttons to move focus, it seems more to be more intellectual. The two kinds of Feeder Calibration Jigs can be applied to all machines, the main differece between these Feeder Calibration Jigs are those base which are used to hold these differnt feeders.
Feeder Calibration Jig for

This is the one with X,Y,Z three axises, we say traditional one.

FEEDER CALIBRATION JIG
With FEEDER CALIBRATION JIG ,you can both check for wheel position in the tape feed direction and function and position of eject pin. The CCD monitor can display inner cross or quadrate or circinal real line or broken line.

It also can simulate feeding like machine running,and the the running speed is adjustable.
FEEDER CALIBRATION JIG SPEC
Display:9 inch CCD Monitor
Master Jig: Depend on your feeder Air pressure: 5 Kg/cm2
Power: AC 110V / 220V
Weight: 30Kg

Feeder Calibration Jig for
This one is without X,Y,Z three axises.

Characteristic
* Easy to manipulate.
* Quite different with the traditional feeder calibration jigs, it has no axixes and guides, just adjust buttons you can move focus with ease, so more durable
* Actual feeding like machine running can be simulated. Also you can control it manually.
* High Definition Industrial CCD with magnifying power 50
* Through a monitor, capable to calibrate all different Sizes and different kinds of feeders using the built-in Line generator.
* Verify and calibrate feeders correctly by using master steel tapes.
* Ligth, beautiful and more durable。
Available for feeders such like Panasonic , Fuji , Juki , Yamaha ,Samsung , KME , Siemens , Sanyo etc
Power AC 110V / 220V 60W
Air pressure:4-5kg/cm2
Volumne:530mm(L)×350mm(W)×580mm(H)
Net Weight :22 Kg; Gross Weight : 36Kg.
